MCB Manufacturer
MCB
Miniature circuit breaker
- Low-voltage circuit breaker. Common standards include IEC 60898-1 and IEC 60947-2
- Rated voltages up to 500V
- Flexible configurations: 1P / 1P+N / 2P / 3P / 4P (18 mm/pole; 27 mm/1P+N)
- Common rated currents: 1A–125A
- Common breaking capacities: 4.5kA / 6kA / 10kA
- Trip curves: B / C / D
- OEM/ODM Accept
- Long mechanical life: 20,000 — suitable for frequent switching and stable long-term protection
MCB, RCCB, RCBO & Distribution Box Manufacturer | Timelec. Keywords: MCB, Miniature Circuit Breaker, MCB manufacturer, mcb factory. TIMELEC supplies miniature circuit breakers to IEC 60898-1 and IEC 60947-2 with B/C/D curves, 1–125A and 4.5/6/10kA options.
MCB Product Range
Browse TIMELEC miniature circuit breakers. View full MCB category
MCB TMM1-125 125A 3P
- Rated current: 125A
- Breaking capacity: 10kA
- Poles: 3P
MCB TMM1-125 4P
- Rated current: up to 125A
- Breaking capacity: 10kA
- Poles: 4P
MCB TMM1-63 3P
- Rated current: 6-63A
- Breaking capacity: 10kA
- Poles: 3P
MCB TMM1-63 C63 10KA 4P
- Rated current: 63A
- Breaking capacity: 10kA
- Poles: 4P
MCB TMM2-63 C63 6KA 1P
- Rated current: 63A
- Breaking capacity: 6kA
- Poles: 1P
MCB TMM2-63 C63 6KA 4P
- Rated current: 63A
- Breaking capacity: 6kA
- Poles: 4P
MCB TMM1-63 10KA 1P
- Rated current: 6-63A
- Breaking capacity: 10kA
- Poles: 1P
TMM1-63 DC 40A MCB
- DC miniature circuit breaker
- Rated current: 40A
- For PV / DC systems
TMM1-125 2P 10KA
- Rated current: up to 125A
- Breaking capacity: 10kA
- Poles: 2P
TMM1-63 10KA 2P
- Rated current: 6-63A
- Breaking capacity: 10kA
- Poles: 2P
TMM1-63 2P 63A DC MCB
- DC miniature circuit breaker
- Rated current: 63A
- Poles: 2P
TMM1-63 DC 63A for Solar
- DC MCB for solar PV
- Rated current: 63A
- Poles: 1P
MCB Trip Curves B / C / D
Choose the trip curve by start-up / inrush current — not by rated current alone. TIMELEC MCBs are available in B, C and D curves for domestic, commercial and industrial distribution.
Type B Curve MCB
More sensitive — for low-inrush loads
Type B is more sensitive and suits loads with small start-up surge, such as lighting, electric heating, general socket outlets, and purely resistive loads.
Type C Curve MCB
Most common — for general motor loads
Type C suits small motors, pumps, fans, air conditioners, and general industrial equipment, and is the most common choice for residential and commercial distribution.
Type D Curve MCB
High inrush tolerance — for heavy start-up loads
Type D is suitable for motors with very large start-up current, high-power transformers, welding machines, large compressors, and other high-inrush industrial equipment.
Why Choose TIMELEC as Your MCB Manufacturer?
TIMELEC is an MCB manufacturer supplying miniature circuit breakers for domestic, commercial and industrial power distribution. Our TMM1 / TMM2 MCB range provides overload and short-circuit protection to IEC 60898-1 and IEC 60947-2, with B/C/D curves, 4.5/6/10kA breaking capacity and accessory-ready modular design. OEM/ODM available for global buyers.
Standards-Compliant Reliability
Designed to IEC 60898-1 and IEC 60947-2 for dependable overload and short-circuit protection.Broad Current & Capacity Range
Series covering common distribution needs with 4.5kA / 6kA / 10kA breaking capacity options.Flexible Curves & Poles
B / C / D trip curves with modular pole configurations for single- and three-phase systems.Accessory Ready
Compatible with shunt tripping, undervoltage/overvoltage release, auxiliary and alarm switches.Technical Specifications
| Parameter | Specification |
|---|---|
| Standard | IEC 60898-1 / IEC 60947-2 |
| Rated current (In) | 1–125A |
| Poles | 1P / 1P+N / 2P / 3P / 4P |
| Rated voltage (Ue) | Up to 500V (series dependent) |
| Insulation voltage (Ui) | 500V |
| Rated frequency | 50/60Hz |
| Rated breaking capacity (Icn) | 4.5kA/6kA/10kA |
| Rated operating short circuit breaking capacity(Ics) | 4.5kA/6kA/7.5kA |
| Tripping curve | B C D |
| Mechanical life | 20,000 |
MCB Manufacturer FAQ
Common questions about TIMELEC miniature circuit breakers.
What is an MCB used for?
An MCB (miniature circuit breaker) provides overload and short-circuit protection in low-voltage AC power distribution. TIMELEC MCBs are used in residential, commercial and industrial panels to protect and control final and sub-distribution circuits.
Which standards do TIMELEC MCBs comply with?
TIMELEC miniature circuit breakers are designed in accordance with IEC 60898-1 for household and similar installations and IEC 60947-2 for industrial low-voltage circuit-breaker applications.
What current ratings and breaking capacities are available?
TIMELEC MCB ranges typically cover common distribution needs from about 1A up to 125A (series dependent), with B/C/D trip curves and 4.5kA / 6kA / 10kA breaking capacity options.
What is the difference between Type B, C and D MCB trip curves?
Type B (about 3–5 × In) suits low-inrush loads such as lighting and heating. Type C (about 5–10 × In) is the most common choice for small motors, pumps, fans and general distribution. Type D (about 10–20 × In) is for high-inrush loads such as large motors, transformers, welding machines and compressors.
Do you offer OEM / ODM as an MCB manufacturer?
Yes. TIMELEC supports OEM/ODM customization for MCB products, including ratings, poles, packaging and private-label branding for distributors and panel builders. TIMELEC is a professional low-voltage products factory, mainly producing MCB, RCBO, MCCB, AFDD, RCCB, distribution boxes, cabinets, and more.
Inquiry Now
Tell us about your MCB requirements and our sales team will contact you with product and configuration support.
